Condensate recovery system

Model: SPT20S (open-type)
Product: Condensate single pump recovery device(open type)
Weight: 280kg
Volume: 1000x750x1688
Normal Pressure: PN16
P.M.A: 1.6MPa/204℃
P.M.O: 1.37MPa/250℃
Flange dimension: HG/T20592;PN16 RF
Power steam consumption: 5kg/t (condensed water)
Power air consumption: 7.6m3/t (condensed water)

Restrictions: The collecting tank (upper tank) is unpressurized and is only used as an open buffer tank.

Part Name
Type
Size
Mat.
Qty.
Part Name
Type
Size
Mat.
Qty.
Pump trap
PT20
DN80/DN50
WCB
1
Steam Trap
STD16F-16
DN15
WCB
1
Check Valve
H71H-16P
DN80 PN16
304
1
B.G.V
WJ41H-16
DN50 PN16
WCB
1
Check Valve
H71H-16P
DN50 PN16
304
1
Base



1
Tank


Q345
1
Ball Valve
Q41H-16C
DN80 PN16
WCB
1
Ball Valve
Q11H-16P
DN25
304
1
Strainer
Y strainer
DN15 PN16
WCB
1
Ball Valve
Q11H-16P
DN25
304
1
Exhaust hose

DN25 PN16
304
1
